Zero-Turn Mower Gravely Pro-Turn MACH ONE 60″EFI

Gravely Mowers are available in all KC Equipment Branches: Yatala, Lismore and Murwillumbah. If you have any questions or need assistance with shipping options, our team at KC Equipment is here to help. Simply click on the enquire online button and follow the prompt or give us a call on 07 3297 3000 for our KC Equipment Yatala office, 02 6622 8122 for our KC Equipment Lismore office and 02 6672 2555 for our KC Equipment Murwillumbah office. We’re looking forward to helping you find the perfect solution!

Description

Gravely Pro-Turn Mach One 60″ EFI: Built to Dominate Overgrown Grass

the Gravely Pro-Turn Mach One 60″ EFI is engineered to power through thick, wet, or overgrown grass with ease. Designed for extreme mowing conditions, this commercial zero-turn mower features a High-Volume Output (HVO) deck with a tunnel chamber that quickly clears clippings, preventing buildup and blade bogging.

Whether you’re tackling tough, stalky growth or oversized properties, the Gravely Pro-Turn Mach One 60″ EFI delivers unstoppable cutting performance and superior efficiency in any terrain.

Key Features of the Gravely Pro-Turn 360 EFI

• HIGH-VOLUME OUTPUT (HVO) DECK – The HVO deck provides increased depth from trim side to discharge side so it can process greater material volume.
• TUNNEL CHAMBER – An advanced cutting chamber is formed by setting the blades back four inches from the front of the deck for less clumping and even grass dispersion.
• Suspension seat is adjustable and has the new addition of a low-profile seat mechanism for added comfort.
• Fully welded tubular frame. One glance and you can see its strength and ruggedness. Its wide front rail distributes weight for superior balance. Also supports the deck lift for easy engagement. Includes a limited lifetime warranty.
• Offers 19 cutting positions, ready to tackle all high grass conditions.
• Foot-Operated deck lift. Forged Aluminium cutter spindles with sealed ball bearings.
• 5 Year/1250 Hour Warranty
• 16cc Parker HTG transmission

Specifications

Warranty Information

• Domestic Warranty: 5 Years / 1250 Hour Domestic Warranty
• Commercial Warranty: 5 Years / 1250 Hour Commercial Warranty
• Hire/Rental Warranty: 90 Day Hire/ Rental Warranty

Miscellaneous

• Blade(s): 3 x Bar Blades

Dimension Specs

• Dry Weight: 681 kg
• Height: 1930 mm With ROPS Up, 1213 mm With ROPS Down
• Width: 1600 mm With Chute Up
• Overall Length: 2190 mm

Zero Turn Mower Specs

• Ground Speed – Forward: Up To 21 km/h Forward
• Ground Speed – Reverse: Up To 9.5 km/h Reverse
• Brakes: Hand Brake
• Seat: High Back Comfort with Suspension & Padded Armrests
• Construction: STEEL Tubular Frame Welded
• ROPS: Foldable ROPS Standard
• Controls: Hand-Operated Choke, Throttle, Ignition Switch, Electric Mower Clutch, Hand Park Brakes
• Cup Holder: Yes
• Deck System: X-Factor® 3 Fabricated
• Deck Lift: Foot Operated
• Deck Construction: Fabricated 7 Gauge w’ 1/4″ Spindle Reinforcement
• Blade Drive: V-Belt Drive to Spindles with Electric Clutch. Spring Tension Idler Pulleys for Extended Belt Life
• Blade Tip Speed: 18,633 FPM
• Spindles: Forged Aluminium with Sealed Ball Bearings
• Drive System: 16cc Parker HTG transmission
• Discharge Chute: High Density, Rubberised
• Steering: Twin-Lever Steering Provides Independent Control of Each Drive Wheel. Speed, Forward, Reverse, and Turns are All Controlled With Hand-Operated Controls.

Engine and Fuel Specs

• Engine: Kawasaki FX1000V EFI
• Engine (cc): 999 cc
• Type: Air Cooled, 90-Degree V-twin, Normally Aspirated Petrol Engine
• HP: 38.5hp
• Cooling: Air Cooled Flywheel Fan
• Fuel: Unleaded Fuel – Maximum of 10% Ethanol in Fuel (See Engine Manufacturers Specifications)
• Fuel Filter: Replaceable, Automotive-Type
• Oil Filter: Spin-On Engine Oil Filter / Total Oil Capacity 1.9 Litres with Filter
• Air Filter: Multi-Stage Remote Canister Heavy Duty Air Filter System
• Fuel Capacity: 50.7L
• Governor: Mechanical

Safety Features

• Safety Features: Operator presence system connected to clutch, seat, and park brakes.

Hydrostatic Drive System Specs

• Drive Cooling: Transmission Mounted Fans

Cutting Dimensions

• Cutting Widths: 60″ (1524 mm) Cut Side Discharge
• Cutting Height(s): 25 mm – 140 mm
