Trimax
Procut FM
The Front Mounted Version Of The Procut
4 Models | 1740–2890mm (69–114") | Suits 30hp+
Pickup Or Delivery
Stock: Enquire Online

Description

The Trimax ProCut FM is a robust machine engineered to withstand everyday use in the toughest commercial environments, yet will deliver a reel-like cut – every time.

In operation the front-mounted version of the ProCut rides on the ground on its front wheels and rear roller. The castoring front wheels allow easy manoeuvring, and combines with the rear roller to follow ground contours and prevent scalping. With the mower in front the operator has no need to look behind, and the tractor wheels do not flatten the uncut grass.

Talk to us today about the capabilities of the ProCut FM in your environment.

Features

Low Maintenance

  • To ensure optimum efficiency, the Procut FM is fitted with reduced maintenance spindles. This removes the tedious task of regular greasing, giving you more time for cutting.

Full Width Rollers

  • The rear roller on the Procut FM follows contours and support the mower across its entire width, providing excellent anti-scalp protection. The mower decks are able to be hung over kerbs and run across concrete areas with no fear of blade strikes.

LazerBladez™

  • Procut FM is fitted with Trimax LazerBladez, a blade system with a carefully engineered centre and gravity and a distinctive tilt-forward blade design, that’s unique to Trimax. LazerBladez provide optimum performance and grass speed.

3 Year Warranty

  • We aim to build mowers that last and we back this up with a 3 year warranty which also includes the spindles and gearboxes. Our robust design coupled with our experienced service and support network ensures minimum downtime and more productivity.

Product Options

Quattro Blade System

  • This system adds 2 more blades to each spindle (2 flat, 2 upturned) for a finer cut on warm season grasses.

Rear Mount

  • Available in rear three-point linkage configuration with front and rear rollers for unmatched safety. For more information please see the ProCut Series 4 Product Page.

Models

P3 178
P3 210
P3 237
P3 290

Specifications

P3 178
Cutting Width – 1740mm (68.5″)
Overall Width – 1884mm (74″)
Height – 1085mm (43″)
Cut Height Range – 10-90mm (3/8″ – 3 1/4″)
No. of Blade Spindles – 3
Approx Weight – 511 kg
Minimum Tractor Size – 30 hp

P3 210
Cutting Width – 2060mm (81″)
Overall Width – 2200mm (87″)
Height – 1085mm (43″)
Cut Height Range – 10-90mm (3/8″ – 3 1/4″)
No. of Blade Spindles – 3
Approx Weight – 608 kg
Minimum Tractor Size – 36 hp

P3 237
Cutting Width – 2316mm (91″)
Overall Width – 2460mm (97″)
Height – 1085mm (43″)
Cut Height Range – 10-90mm (3/8″ – 3 1/4″)
No. of Blade Spindles – 4
Approx Weight – 641 kg
Minimum Tractor Size – 40 hp

P3 290
Cutting Width – 2890mm (114″)
Overall Width – 3130mm (123″)
Height – 1085mm (43″)
Cut Height Range – 10-90mm (3/8″ – 3 1/4″)
No. of Blade Spindles – 5
Approx Weight – 780 kg
Minimum Tractor Size – 45 hp


Manufacturer’s Website

Trimax – www.trimaxmowers.com.au


Have a question about this product? Call or visit our stores or enquire online.
