Trimax
Flaildek FX
Trimax Flail Technology For Out Front Operation
3 Models | 1342–1830mm (53–72")
Pickup Or Delivery
Stock: Enquire Online

Description

The Trimax FlailDek FX offers a high performance alternative to the standard factory-fitted rotary mowing attachments found on John Deere, Kubota, Iseki, New Holland, Shibaura and Hustler out-front tractors. It has the ability to deliver an exceptionally clean cut and disperse clippings safely. FlailDek FX is suitable for sports grounds, roadsides, schools, parks and other fine turf applications.

Features

3 Year Warranty

  • We aim to build mowers that last and we back this up with a 3 year warranty. Our robust design coupled with our experienced service and support network ensures minimum downtime and more productivity.

Rear Roller

  • The full width rear roller prevents unsightly scalping and permits the edge of the mower to be run along kerbs and banks without fear of blade strike. The roller also adds to overall safety and produces a brilliant striping effect for those wishing to pattern their turf.

Unique Converter™

  • Trimax’s unique and Patented Converter feature, when lowered, allows superb short grass cutting ability by creating airflow that lifts the grass before it’s cut. For work in heavy environments the Converter can be quickly lifted allowing more grass to be processed within the mower to increase productivity.

Power Saving Flails

  • One of the many secrets of the FlailDek FX’s success is the exclusive Trimax Gamma™ flail. Formed from high tensile alloy steel and hardened for long life, the straight cutting edge produces a perfectly even cut. The aerodynamic profile reduces horsepower requirements, yet generates sufficient draught to prevent clogging, and lifts the grass for a clean cut. The low power requirements offer a huge advantage, especially in heavy conditions.

Models

FXU 135
FXU 155
FXU 185

Specifications

FXU 135
Cutting Width – 1342mm (53″)
Overall Width – 1560mm (61″)
Overall Length – 1095mm (43″)
Cut Height Range – 12-102mm (1/2″ – 4″)
Approx Weight – 210kg
Hydraulic Drive – N/A
Warranty – 3 Years

FXU 155
Cutting Width – 1520mm (60″)
Overall Width – 1720mm (68″)
Overall Length – 1095mm (43″)
Cut Height Range – 12-102mm (1/2″ – 4″)
Approx Weight – 225kg
Hydraulic Drive – Optional (Specific Tractors Only)
Warranty – 3 Years

FXU 185
Cutting Width – 1830mm (72″)
Overall Width – 2045mm (81″)
Overall Length – 1095mm (43″)
Cut Height Range – 12-102mm (1/2″ – 4″)
Approx Weight – 250kg
Hydraulic Drive – N/A
Warranty – 3 Years


Manufacturer’s Website

Trimax – www.trimaxmowers.com.au
